Separate an Input into Two Orthogonally Polarized Beams Yttrium Orthovanadate Substrate is Transparent from 488 nm to 3.4 m Calcite Substrate is Transparent from 350 nm to 2.3 m 2.7 mm and 4.0 mm..
Birefringent Crystal Beamsplitters
|
||
Type
|
Ordinary Ray Anglea
|
Extraordinary Ray Anglea
|
Calcite Beam Displacers
|
Parallel
|
Parallel
|
YVO4 Beam Displacers
|
Dimension tolerance
|
±0.1mm
|
parallism
|
<15sec
|
perpendicular
|
<15min
|
Flatness
|
<λ/8@632.8nm
|
Wavefront Distortion
|
<λ/4@632.8nm
|
Surface Quality
|
20/10
|
Clear Aperture
|
>90%
|
Coating
|
Upon request
|
Note:Custom designs for other sizes and coatings are also available upon request
