Potassium Titanyl Phosphate (KTP) Crystal
KTP crystal is grown by improved Flux growingtechnology and high purity chemical. It is featured with extremelow absorption at the fundamental and second harmonicgeneration wavelengths. We supply standard KTP crystal andcustomer-designed KTP crystal for various applications.
KTP Crystal is Featured:
*Large Nonlinear Optical (NLO) Coefficient
*Wide Angular Bandwidth and Small Walk-off Angle
*Broad Temperature and Spectral Bandwidth
*High Electro-Optic (E-O) Coefficient and Low Dielectric Constant
*Good Chemical and Mechanical Properties.
Applications:
Frequency Doubling (SHG) of Nd-doped Lasers for Green/Red OutputParametric Sources (OPG, OPA and OPO) for 600nm-4500nm Tunable OutputE-O ModulatorsOptical Waveguides for Integrated Optics and E-O Devices
UPT offers KTP specification:
|
Tolerance of dimension
|
Dimension+/-0.1 mm，L：±0.1mm
|
|
Flatness
|
λ/8 @ 632.8nm
|
|
Wavefront distortion
|
<λ/4@ 632.8nm
|
|
Surface quality
|
10/5 per MIL-O-13830A
|
|
Parallelism
|
10″
|
|
Perpendicularity
|
5′
|
|
Bevel/chamfer
|
<0.1mm@45deg.
|
|
Chips
|
<0.1mm
|
|
Angle Tolerance
|
△θ≤±0.5°, △φ≤±0.5°
|
|
Coating
|
AR/HR/P- coating Upon request
|
|
Warranty
|
One year under proper use
|
Note: OEM Dimension, different axis angle cutting and coating and damage threshold upon request, others are available upon request.
